Single Strand Roller Chain Specifications (ANSI/ISO Equivalent)
Column Definitions
- Chain No. (ANSI/ISO) – Standard chain designation
- Pitch (P) – Distance between pin centers (inches or mm)
- Roller Diameter (d1 max) – Maximum roller diameter
- Width Between Inner Plates (b1 min) – Minimum inner width
- Pin Diameter (d2 max) – Maximum pin diameter
- Pin Length (L max) – Overall pin length
- Connecting Link Pin Length (Lc max) – Pin length for connecting link
- Inner Plate Height (h2 max) – Height of inner plate
- Plate Thickness (T max) – Thickness of chain plate
- Minimum Tensile Strength (Q min) – Breaking load (kN / lbf)
- Average Tensile Strength (Qo) – Typical measured strength (kN)
- Weight per Meter (q) – Chain weight (kg/m)
Example Rows (Converted to English Format)
Light Series
| Chain No. | Pitch (mm) | Roller Dia (mm) | Width (mm) | Pin Dia (mm) | Pin Length (mm) | Plate Thickness (mm) | Tensile Strength (kN) | Weight (kg/m) |
|---|---|---|---|---|---|---|---|---|
| 03C | 4.7625 | 2.48 | 2.38 | 1.62 | 6.10 | 0.60 | 1.80 | 0.08 |
| 04C | 6.35 | 3.30 | 3.18 | 2.31 | 7.90 | 0.80 | 3.50 | 0.15 |
| 06C | 9.525 | 5.08 | 4.77 | 3.58 | 12.40 | 1.30 | 7.90 | 0.33 |
| 08A | 12.70 | 7.95 | 7.85 | 3.96 | 16.60 | 1.50 | 14.10 | 0.62 |
| 10A | 15.875 | 10.16 | 9.40 | 5.08 | 20.70 | 2.03 | 22.20 | 1.02 |
ANSI Standard Series
| Chain No. | Pitch (mm) | Roller Dia (mm) | Width (mm) | Pin Dia (mm) | Pin Length (mm) | Plate Thickness (mm) | Tensile Strength (kN) | Weight (kg/m) |
|---|---|---|---|---|---|---|---|---|
| 04B-1 | 6.00 | 4.00 | 2.80 | 1.85 | 6.80 | 0.60 | 3.0 | 0.11 |
| 05B-1 | 8.00 | 5.00 | 3.00 | 2.31 | 8.20 | 0.80 | 5.0 | 0.20 |
| 06B-1 | 9.525 | 6.35 | 5.72 | 3.28 | 13.15 | 1.30 | 9.0 | 0.41 |
| 08B-1 | 12.70 | 8.51 | 7.75 | 4.45 | 16.70 | 1.60 | 18.0 | 0.69 |
| 10B-1 | 15.875 | 10.16 | 9.65 | 5.08 | 19.50 | 1.70 | 22.4 | 0.93 |
Double Strand Roller Chain Specifications (Duplex Chain)
Column Definitions
- Chain No. (ANSI/ISO) – Chain designation (duplex = “-2”)
- Pitch (P) – Distance between pin centers
- Roller Diameter (d1 max) – Maximum roller diameter
- Width Between Inner Plates (b1 min) – Minimum inner width
- Pin Diameter (d2 max) – Maximum pin diameter
- Pin Length (L max) – Overall pin length
- Connecting Link Pin Length (Lc max) – Length for connecting link pins
- Inner Plate Height (h2 max) – Height of inner plate
- Plate Thickness (T max) – Thickness of plates
- Transverse Pitch (Pt) – Distance between the two strands
- Minimum Tensile Strength (Q min) – Minimum breaking load
- Average Tensile Strength (Qo) – Typical measured strength
- Weight per Meter (q) – Chain mass per meter
ANSI A-Series Duplex
| Chain No. | Pitch (mm) | Roller Dia (mm) | Width (mm) | Pin Dia (mm) | Pin Length (mm) | Plate Thickness (mm) | Transverse Pitch (mm) | Tensile Strength (kN) | Weight (kg/m) |
|---|---|---|---|---|---|---|---|---|---|
| 04C-2 | 6.35 | 3.30 | 3.18 | 2.31 | 15.5 | 0.80 | 6.40 | 7.0 | 0.28 |
| 06C-2 | 9.525 | 5.08 | 4.77 | 3.58 | 22.5 | 1.30 | 10.13 | 15.8 | 0.63 |
| 08A-2 | 12.70 | 7.95 | 7.85 | 3.96 | 31.0 | 1.50 | 14.38 | 28.2 | 1.12 |
| 10A-2 | 15.875 | 10.16 | 9.40 | 5.08 | 40.4 | 2.03 | 18.11 | 44.4 | 2.00 |
| 12A-2 | 19.05 | 11.91 | 12.57 | 5.94 | 48.8 | 2.42 | 22.78 | 63.6 | 2.92 |
ANSI B-Series Duplex
| Chain No. | Pitch (mm) | Roller Dia (mm) | Width (mm) | Pin Dia (mm) | Pin Length (mm) | Plate Thickness (mm) | Transverse Pitch (mm) | Tensile Strength (kN) | Weight (kg/m) |
|---|---|---|---|---|---|---|---|---|---|
| 05B-2 | 8.00 | 5.00 | 3.00 | 2.31 | 13.9 | 0.80 | 5.64 | 8.7 | 0.33 |
| 06B-2 | 9.525 | 6.35 | 5.72 | 3.28 | 23.4 | 1.30 | 10.24 | 16.9 | 0.77 |
| 08B-2 | 12.70 | 8.51 | 7.75 | 4.45 | 36.1 | 1.60 | 16.59 | 44.5 | 1.34 |
| 10B-2 | 15.875 | 10.16 | 9.65 | 5.08 | 36.1 | 1.70 | 16.59 | 44.5 | 1.84 |
| 12B-2 | 19.05 | 12.07 | 11.68 | 5.72 | 42.0 | 1.85 | 19.46 | 57.8 | 2.31 |
Triple Strand Roller Chain Specifications (Triplex Chain)
Column Definitions
- Chain No. (ANSI/ISO) – Chain designation (triplex = “-3”)
- Pitch (P) – Distance between pin centers
- Roller Diameter (d1 max) – Maximum roller diameter
- Width Between Inner Plates (b1 min) – Minimum inner width
- Pin Diameter (d2 max) – Maximum pin diameter
- Pin Length (L max) – Overall pin length
- Connecting Link Pin Length (Lc max) – Connecting link pin length
- Inner Plate Height (h2 max) – Inner plate height
- Plate Thickness (T max) – Plate thickness
- Transverse Pitch (Pt) – Distance between strands
- Minimum Tensile Strength (Q min) – Minimum breaking load
- Average Tensile Strength (Qo) – Typical tensile strength
- Weight per Meter (q) – Chain weight
ANSI A-Series Triplex
| Chain No. | Pitch (mm) | Roller Dia (mm) | Width (mm) | Pin Dia (mm) | Pin Length (mm) | Plate Thickness (mm) | Transverse Pitch (mm) | Tensile Strength (kN) | Weight (kg/m) |
|---|---|---|---|---|---|---|---|---|---|
| 04C-3 | 6.35 | 3.30 | 3.18 | 2.31 | 21.0 | 0.80 | 6.40 | 10.5 | 0.44 |
| 06C-3 | 9.525 | 5.08 | 4.77 | 3.58 | 33.5 | 1.30 | 10.13 | 23.7 | 1.05 |
| 08A-3 | 12.70 | 7.95 | 7.85 | 3.96 | 46.4 | 1.50 | 14.38 | 42.3 | 1.90 |
| 10A-3 | 15.875 | 10.16 | 9.40 | 5.08 | 57.0 | 2.03 | 18.11 | 66.6 | 3.09 |
| 12A-3 | 19.05 | 11.91 | 12.57 | 5.94 | 71.5 | 2.42 | 22.78 | 95.4 | 4.54 |
ANSI B-Series Triplex
| Chain No. | Pitch (mm) | Roller Dia (mm) | Width (mm) | Pin Dia (mm) | Pin Length (mm) | Plate Thickness (mm) | Transverse Pitch (mm) | Tensile Strength (kN) | Weight (kg/m) |
|---|---|---|---|---|---|---|---|---|---|
| 05B-3 | 8.00 | 5.00 | 3.00 | 2.31 | 19.5 | 0.80 | 5.64 | 11.1 | 0.48 |
| 06B-3 | 9.525 | 6.35 | 5.72 | 3.28 | 33.5 | 1.30 | 10.24 | 24.5 | 1.16 |
| 08B-3 | 12.70 | 8.51 | 7.75 | 4.45 | 45.1 | 1.60 | 13.92 | 47.5 | 2.03 |
| 10B-3 | 15.875 | 10.16 | 9.65 | 5.08 | 52.7 | 1.70 | 16.59 | 66.7 | 2.77 |
| 12B-3 | 19.05 | 12.07 | 11.68 | 5.72 | 61.5 | 1.85 | 19.46 | 86.7 | 3.46 |
